INTECH Interactive Touch Led Panel
Your are here: Home > Smart Classroom >Interactive Flat Panel

INTECH Interactive Touch Led Panel

  • 20 points touch
  • Screen share
  • Instant whiteboard lesson delivery software
  • Front-facing speakers
  • Android module include, OPS PC as optional
  • UHD 4K screen, anti-glare glass
Features Specifications Dimensions Video
  • Led interactive touch screen
  • IR touch technology
  • 20 touch, write on the board by finger/pen
  • Dual OS: Windows + Android OS
  • OPS Computer: i3 CPU, 4G RAM, 500G HDD, WIFI, Windows 7/10, optional discrete graphics
  • Wall mount brackets included
  • Fingerprint locker as optional
  • Front meeting camera as optional
  • HDMI 1.4

  • Model

    TS65DW

    TS75DW

    TS85DW

    TS98DW

  • Display

  • Panel Size (diagonal)

    65"75"85"98"

  • Resolution

    4k 3840(H)*2160(V)

  • Brightness

    550cd/㎡

  • Dynamic Contrast

    10000:1

  • View Angle

    178°

  • Backlight

    LED

  • Transmission Speed

    5m/s

  • Lifespan

    50,000 hrs

  • Glass

    4 mm fully tempered anti-glare explosion-proof glass

  • Power

  • Input Voltage

    90 V ~ 240 V/AC, 50/60 Hz

  • Standby Power

    ≤0.5W

  • Power Consumption

    ≤300W (not include ops)

  • OS

  • Android Version

    Android 8.0

  • Chip set

    MSD8386 CA53*2+CA73*2 1.5GHz

  • Storage

    2G DDR4 + 16G Standard (3G+32G optional)

  • Ports

  • LAN_IN*1, LAN_OUT*1, VGA*1, Audio in*1, YPBPR*1, AV in*1, AV out*1, EAR PHONE*1, RF*1, coaxial SPDIF*1, HDM*2, Touch*1, RS232*1, USB*2, WIFI*3, HDMI OUT*1(customize required)

  • TV

  • ATV

    ATV (PAL/SECAM)

  • DTV

    DTMB

  • PC/Audio/Video IN

    support 3840*2160P

  • Multimedia Video

    MPEG-2/4, AVS, H.264, H.265, TS, Realmedia...

  • Multimedia Audio

    MPEG1/2 layerI/II, AAC-Lc, WMA...(customize required)

  • Analog Video Cvbs

    1.0 Vp-p±10%

  • Analog Video YPvPr

    480i/480P/576i/576P/720P/1080i/1080P

  • HD Video HDMI Input

    480i/480P/576i/576P/720P/1080i/1080P/2160P

  • Channel

    200

  • Speakers

    8Ω/20W*2

  • Touch

  • Technology

    IR 20-point touch HID free driver

  • Response Time

    <6ms

  • OS

    Windows7, Windows10, Mac, Linux, Android

  • OPS PC (Optional)

  • CPU

    Intel core (i3/i5/i7 for optional)

  • HDD

    SSD 128G/256G/480G; HDD 500G/1TB (for optional)

  • Storage

    4GB/8GB DDR3/DDR4

  • WiFi

    support

  • OS

    Window XP, Window 7/8, Window 10, Linux for options

  • Warranty

  • 1 year as standard, 3 years as optional

  • Certification

  • CE, ROHS, FCC
